Project Gallery

Our sites, our systems, our people.

A project-by-project look at ACL's transmission, substation and construction work across Bangladesh.

Meghnaghat–Madhumati 400KV Double Circuit Line

Client: KEC International Limited Scope: Transmission line installation Location: Meghnaghat–Madhumati
Pile cap foundation casting — KEC Meghnaghat–Madhumati line Bamboo scaffold and conductor stringing setup — KEC Meghnaghat–Madhumati line Rebar cage foundation works in paddy field — KEC Meghnaghat–Madhumati line Tower structure assembly in paddy field — KEC Meghnaghat–Madunaghat line Transmission tower erection — KEC Meghnaghat–Madunaghat line

400KV Double Circuit Rooppur–Dhaka Transmission Line

Client: L&T Ltd Scope: Piling and foundation works Location: Tangail
Piling rig at tower foundation — L&T Rooppur–Dhaka line, Tangail Crane-mounted piling work — L&T Rooppur–Dhaka line, Tangail Site team at Tangail — L&T Rooppur–Dhaka 400KV line

Underground Cable Line Installation — English Road to Bangabhaban

Client: Moon Power Engineering Ltd / TBEA Co. Scope: Underground cable line installation Location: English Road to Bangabhaban
Cable trench excavation — English Road to Bangabhaban Trench lining work — English Road to Bangabhaban Night trenching works — English Road to Bangabhaban Compaction work at cable trench — English Road to Bangabhaban

DPDC Underground Power Cable Line — TBEA-ACL Package #03

Client: TBEA Co., Ltd. Scope: Underground cable line installation (HDD road & lake crossings) Location: Siddirganj, Munshikhola, Bhuighor, Tatibazar & DPDC network area
Cable rack installation — Shiddirganj to Lamapara, 2nd section Cable pulling in trench — Shiddirganj to Lamapara section Bamboo scaffold cable trench — Shiddirganj substation section Cable trench along roadside — Shiddirganj to Lamapara section HDD works — Lot-6, 90m, Bhuighor HDD pipe pulling — Lot-2, 129m, Siddirganj HDD works — Lot-02, 129m, Siddirganj HDD works at night — Lot-10, 98m, English Road, Tatibazar More HDD road crossing at night — Tatibazar More, 80m, 12 nos crossings HDD crossing — Lot-19 JB-6 to JB-7, 188m, RHD bituminous road crossing HDD crossing — Lot-19 JB-5 to JB-6, 158m & 202m, RHD road & lake crossing HDD crossing — Lot-19 JB-5 to JB-6, 158m & 202m, RHD road & lake crossing HDD crossing — Lot-19 JB-4 to JB-5, 210m, RHD road crossing HDD pipe laying — Lot-19 JB-4 to JB-5, 210m, RHD road crossing HDD trench works — Lot-19 JB-4 to JB-5, 210m, RHD road crossing HDD trench works — Lot-19 JB-4 to JB-5, 210m, RHD road crossing HDD trench works — Lot-19 JB-4 to JB-5, 210m, RHD road crossing HDD works — Lot-19, 170m, Munshikhola HDD pipe pulling works at night — Package #3 Night HDD works — Package #3 HDD works — Lot-17, 146m, Lamapara HDD works — Lot-17, 146m, Lamapara
